Engine Noise and Vibration

The micro Drivven Combustion noise Analysis( μDCAT) Software :-.
B&K 4374 - Miniature piezoelectric charge accelerometer
B & K 4192 - Pressure-field microphone

Title of image on left

Brief description of what the image on left is about

Equipment Name

Engine acoustics & vibration facility

The micro Drivven Combustion noise Analysis( μDCAT) Software:

Engine noise, vibration testing and analysis.
The micro Drivven Combustion Analysis Tool (μDCAT) is used to perform Engine combustion and noise analysis.
It is the combustion analysis tool from National Instruments and it requires NI Compact DAQ 9178 Chassis and NI 9215 module.

B& K 4374 - Miniature piezoelectric charge accelerometer:

Type 4374 is a piezoelectric, Planar Shear accelerometer.
It is able to withstand high temperature on the engine surface and is able to measure engine vibration.
High-level, high-frequency measurements, measurements in confined spaces and on delicate structures are possible
Vibration testing and analysis can be performed.

B & K 4192 - Pressure-field microphone, 3.15 Hz to 20 kHz, 200V polarization:

Type 4192 is designed for high-precision noise measurements. Being externally polarized, Type 4192 should be used with a classical pre-amplifier.
Pressure-field microphones are optimised to have a flat frequency response in a pressure field. The microphones are used for making measurements in small, closed couplers or close to hard, reflective surfaces
Type 4192 is suited for situations, where a robust and stable pressure-field microphone is required and it is well suited for the engine noise applications.

+ - List of testing, research and consulting areas where it can be useful Click to collapse

Engine noise, vibration testing and analysis.
Development of technology for Engine noise and vibration reduction.
Effect of different injection strategies on engine noise and vibrations.
Engine noise and vibration optimization.
Effect of Biofuels on Engine Noise and Vibration.

+ - List of keywords for which it should be findable Click to collapse

Acoustics, Engine noise, vibration, injection strategies

+ - Links for videos related to the facility Click to collapse

None

+ - Location info Click to collapse

Engine Research Laboratory, IIT Kanpur

+ - Timings for use Click to collapse

Contact Prof. Avinash Kumar Agarwal

+ - Access procedure Click to collapse

Contact Prof. Avinash Kumar Agarwal

+ - Contact person Click to collapse

DrAvinash K Agarwal, FSAE, FASME
Department of Mechanical Engineering
Indian Institute of Technology Kanpur
Kanpur-208016 India
Home Page: www.iitk.ac.in/erl
Tel: +91 512 2597982 (Off)
+91 512 2598682 (Res)
Fax: +91 512 2597982, 2597408 (Off)

+ - Contact info Click to collapse

Engine Research Laboratory
Department of Mechanical Engineering
IIT Kanpur, Kanpur-208016
Tel: +91 512 2597458 (Lab)

+ - Any other key information Click to collapse

None
