Facilities

This lab is equipped with various kind of instruments related to manufacturing process like casting, metal forming, forging, joining (welding and brazing), etc. The available facilities of this lab are given below-


Hydraulic Press Machine


  • Capacity: 200 Ton
  • Cold Forging: (1.0 cm- 70 cm)
  • Hot Forging: (2.0 cm-10 cm)
  • Materials: Al, Cu , Lead, Low carbon steel

Cold Rolling


  • Roll Diameter: 5"
  • Roll Speed: 72 RPM
  • Capacity: 0.5 mm thin to 16 mm thick (L & W 100 mm X 30 mm)
  • Materials: Al, Cu, Iron, SS, Brass, etc

Hot Rolling


  • Capacity: 0.5 mm thin to 16 mm thick
    (L & W 100 mm X 30 mm)
  • Materials: Al, Cu, irons, SS, Brass, etc.

MMAW, MAG


  • Capacity: Pool Size (1.0 mm- 10 mm)
  • Materials: Mild Steel, Stainless Steel

Tungsten Inert Gas Welding


  • Type: Inert Gas Welding
  • Capacity: Pool size (10 mm)
  • Materials: Aluminium, Stainless Steel

Brazing Set


  • Type: Oxyacetylene Gas
  • Capacity Thin section and different type materials joining
  • Materials Cu, Iron, SS, Brass, MS etc.

Induction Furnace


  • Type: Electric
  • Capacity: Maximum temperature- 1400 oC
  • Materials: Aluminium, Cast Iron

Electric Furnace


  • Type: Mini Induction
  • Capacity: Maximum Temperature- 1100 oC
  • Materials: Aluminium

Tube Furnace


  • Type: Electric heater (Ceramic Tube)
  • Capacity: Max dia. 25 mm, Max Temperature- 950 oC
  • Materials: Al, Cu, Iron, SS, Brass etc.

Injection Molding Machine


  • Type: Inject (Tensile Sample)
  • Capacity: 4.0 mm thickness
  • Materials: LDPE, HDPE & Granules, 5%Alumina, Cu powder

Swaging Machine


  • Type: Rotary
  • Capacity: Max dia. 12.5 mm to Min. 3.5 mm
  • Materials: Al, Cu, Iron, SS, Brass, etc.

Shearing Machines


  • Capacity: 0.5 mm thin to 3.0 mm thick
    (Width limitation 45" inch)
  • Materials: Aluminium Sheets & Mild Steel Sheets

Hardness Tester


  • Type: Rockwell
  • Capacity: 1.5 mm thin to 10 mm thick
    (L & W, 80 mm X 80 mm)
  • Materials: Aluminium and Iron

Compaction Machine


  • Type of compaction: Cold
  • Capacity: Min. thickness 2.0 mm & dia- 15 mm
    Max. thickness 8.0 mm & dia- 25 mm
  • Materials: Al, Cu & Fe powder

Permiability Meter (VP)


  • Application: To determine permeability number of green sand, core sand and raw sand.
  • Description: Permeability measures the venting characteristics of green sand.
    Permmeter employs the orifice method for the rapid determination of sand permeability.
    It is manually operated machine
  • Range: Big Orifice-36 to 2450 No.
    SmallOrifice-1.1 to 49No.

Ender 3 Pro DIY Printer


  • The creality 3D Ender 3 Pro provides an all-round protection to your 3D printer build plate and ensure consistent temperature throughout the build surface.
  • The Ender 3 Pro in India comes with a UL Certified power supply, protecting your printer from unexpected power surges, that can heat the hot bed to 110oC in just 5 minutes.
  • Ender 3 Pro has the ability to resume printing from the last recorded extruder position after suffering unexpected power outages.
  • The DIY kit of the Creality Ender 3 Pro in India is an easy-to-setup kit and comes with partially assembled components, allowing you to learn about the basic construction of 3D printers as you finish putting it together.
